Material & Safety
Fabric | Fiberglass |
Fire Safety | Must comply with EN 45545-2 HL2 |
Toxicity/Smoke | Low smoke emission, halogen-free |
Light & UV Control
Blackout Type | <10% light transmission |
UV Blocking | ≥ 70% UV protection (to protect passengers & interior) |
Anti-glare surface finish | |
Mechanical Design
Operation | Side-guided |
End Fittings | Aluminium or Stainless Steel |
Roller Tube | Aluminium alloy |
Brackets | Powder-coated steel or aluminium |
Pull Mechanism | Pull strap, bead chain, or handle |
Life Cycle | ≥ 20,000 up/down cycles without failure |
Environmental Durability
Temperature Resistance | -25 °C to +70 °C (no deformation) |
Humidity Resistance | Up to 95% RH |
UV Resistance | No fading after ≥ 500 hours exposure |
Cleaning | Resistant to alcohol-based and mild detergent cleaners |
Dimensions & Fitment
· Customized to window frame.
· Mounting: Integrated into the upper window frame, concealed when rolled up.
· Vibration Resistance: Must withstand train vibration & shock (IEC 61373-2010).
